Binding hot melts
TOYOMELT™ TM Series
The hot melts TOYOMELT ™ TM series for bookbinding is a specialized hot melts for bookbinding applications, available in both back and side glue. In addition, we have a wide range of product lineups that meet your needs, such as general-purpose types, strong adhesive types, and low-temperature coating types, and we have a lot of experience in the bookbinding market.
In addition, products for backing glue have passed the "difficult tearing test" and correspond to the A rank of the "Guidelines for the Production of Recyclable Printed Materials" stipulated by the Japan Federation of Printing Industries. It is an environmentally friendly hot melts that is recyclable.
- Application example
- TOYOMELT™ TM Series main products list
- Reactive hot melts (PUR-HM) for Bookbinding Back Glue
Application example
Bookbinding applications (back glue and side glue)
TOYOMELT™ TM Series main products list
| Product name | Applications | Softening point | Open time (seconds) | Features |
|---|---|---|---|---|
| TM-2602 | Back glue | 107 | 10 s to 12 s | General purpose type, low generation of oil smoke |
| TM-2780 | Back glue | 104 | 8 s to 9 s | Excellent resistance to solvents and peeling of cover paper |
| TM-2486 | Back glue | 93 | 8 s to 9 s | Excellent hue change over time (good heat resistant hue) |
| TM-894 | Side glue | 89 | 14 s to 16 s | General-purpose type, yarn pulling reduction |
In addition to the above products, there are a wide range of lineups depending on the application and coating environmental.
Reactive hot melts (PUR-HM) for Bookbinding Back Glue
For bookbinding applications, in addition to TOYOMELT™ TM series above, we also offer TOYOMELT™ UM series, a reactive hot melt (PUR-HM) specialized for back glue.
Reactive hot melts is a adhesives that chemically react after heating and dissolving by causing a chemical reaction with moisture contained in air or paper, and then harden. Compared to conventional EVA-based hot melts adhesives, it has a strong adhesive strength, excellent spreadability, heat andcold resistance which makes it possible to make books that open well to the knod side, that are durable and long lasting.
TOYOMELT ™ UM Series Main Products for Bookbinding Back Glue
| Product name | Appearance | Viscosity 125℃ (mPa・S) | Set time | Solidification rate | Residual MDI (%) | Applications/features |
|---|---|---|---|---|---|---|
| UM-7032 | Milky white | 7100 | 20～22 | 4 min 15 s | ＜1 | For bookbinding/MDI reduction product |
| UM-7335B | Yellow | 7300 | 26～28 | 4 min 45 s | 2~3 | For bookbinding |
In addition to the products listed above, we have a wide range of products with different adhesion strengths depending on the type of paper base material and application.
