Raising varnish series TU763 FDSS gloss varnish

TU763 FDSS Gloss Varnish is a screen ink that adds design features such as texture and three-dimensionality to offset/gravure prints by applying a thin film of UV screen printing to the prints. It has excellent fine line reproducibility, making it suitable for printing high fine line patterns.

Dry curing method

UV curing type

Packing

5kg

Purpose/Function

Tubes, bottles, meter panels, pseudo-etching, amusement, Braille, thick embossing, high-definition, metal, displays, nameplates, packages, cards, plastic moldings, books, insulation

Base material

PC, ABS, PVC, treated PET, treated PP, treated PE, paper, synthetic paper

Base material (other)

Can be used on substrates such as UV/oil-based offset prints, inkjet prints, gravure prints, and treated PP laminates.

Printability

Leveling properties, curing properties, fine line reproducibility

Post-processability

Recoatability, punchability

Paint film appearance

Gloss, transparency, non-yellowing

Paint film properties

Abrasion resistance

Resistance

Heat resistance, hot water-based resistance, weather resistance

Paint film strength

Tough coating, flexibility

Chemical Resistance

Acid resistance, alkali resistance, alcohol resistance, solvent resistance, oil resistance, gasoline resistance

Electrical properties

Insulation

Characteristics (other)

It has extremely high fine line reproducibility.
It is possible to obtain a film with high gloss, high transparency, and low yellowing.
It has good curing properties and excellent blocking resistance.
Excellent adhesion to various substrates such as offset printed materials and treated PP laminates.
Excellent compatibility with our inks such as FD Calton series, FDO New series, TK NEX series, etc.

Finish, texture, appearance effect

Gloss (glossy)

Heat dry curing conditions

120W/cm 1 metal halide lamp 10m/min (total light intensity 300mJ/cm2)

Auxiliary agents, additives, cleaning solvents, etc.

Viscosity modifier (diluent): FDSS 320 Regiuser (~5% added to ink)
SS Plate Cleaner ECO Series...A plate cleaning agent for screen printing that does not fall under organic regulations or the PRTR law. SD is the standard type, and QD is even faster drying.

Physical properties

Test ink: TU763 FDSS gloss varnish
Plate: 420 mesh (emulsion thickness 100μm, printing film thickness approximately 10μm)
Curing conditions: 120W/cm metal halide lamp 10m/min

Item	Test method	Evaluation results
Adhesion	After cross-cutting at 1mm intervals, attach 18mm wide cello tape and evaluate the degree of peeling when it suddenly peels off (adhesion to PP laminate)	Good
flexibility	Evaluation based on the degree of cracking, sound, and peeling caused by bending at 180 °C	Good
Blocking property	Evaluate the degree of blocking after placing the printed surfaces on top of each other under a load of 100g/cm2, temperature of 40 ℃, and humidity of 80 % and leaving them for 24 hours.	Good
Leveling property	Visually evaluate the smoothness of the solid printing surface	Good
transparency	Visually evaluate the transparency of printed matter	Good
yellowing	Visually evaluate the degree of yellowing of printed matter	Good
luster	Visually evaluate the gloss of printed matter	Good

Other product data

Viscosity: 9.0±1.0 Pa・S (B type viscometer rotor No.4 12RPM/25℃)

Requests for use

This document is an example of our test data, and the properties obtained will vary depending on printing/processing conditions, base materials, etc., and are not guaranteed.
Before using the product, please carefully check its intended use.
Before handling this product, be sure to read the "Product Safety Data Sheet" and handle with care.
If you wish to export this product overseas, please be sure to check with us.
